SwiftLaser® SLD100

The SwiftLaser® SLD100 is a standalone desktop laser engraver purpose-built for secure ID card personalization. Available in 3W and 10W DPSS configurations, as well as a 20W MOPA fiber option, it delivers precision laser engraving for a wide range of vertical markets.

Explore

SwiftLaser® SLD100

Security
  • State of the art standalone desktop laser engraver
  • Hopper and laser module benefit from a secure lock and key mechanism
  • Polycarbonate substrate is permanently changed when personalized, making documents extremely difficult to forge
  • CLI (Changeable Laser Image) security engraving - standard
Print Capabilities
  • Vector and raster graphics
  • Flipping mechanism for front and back side engraving
  • Automatic 100 card input card feeder and 100 card output feeder
  • Micro text, guilloche, barcode, QR code, tactile and embossed effects for customization
Durability
  • Low maintenance
  • 10-year life for ID cards
  • Laser light is the ultimate choice for high UV stability, preventing fading
Image Quality
  • High quality laser engraving delivering up to 1200 DPI resolution
Warranties
  • 12 month warranty

SwiftLaser® SLD100

Desktop Laser Printer

The SwiftLaser® SLD100 is a standalone desktop laser engraver designed for secure ID card personalization across a range of vertical markets. Available in 3W and 10W DPSS configurations, along with a 20W MOPA fiber option, it supports both decentralized and centralized issuance programs.

The SLD100 feeds cards in portrait orientation, making it an independent desktop unit - not designed to operate as an add-on to a card printer. Its precision laser engraving permanently alters the polycarbonate card surface, producing credentials that are extremely difficult to modify, forge, or counterfeit.

Standard on every SLD100 is CLI (Changeable Laser Image) security engraving, which produces variable images when the card is tilted side to side. MLI (Multiple Laser Image) - variable images when the card is tilted top to bottom - is available as an upgrade option.

With increasing demand for secure, durable identity solutions, the SwiftLaser® SLD100 helps agencies and organizations improve authentication, prevent fraud, and produce credentials with a higher level of built-in security.

Technical Specification

Standard Features

Available laser configurations: 3W DPSS, 10W DPSS, and 20W MOPA fiber
Standard CLI (Changeable Laser Image) security engraving with optional MLI (Multiple Laser Image)
Up to *120 cards per hour single-sided
Up To 60 cards per hour dual-sided
High resolution 256 greyscale picture engraving
XY offset registration - via optional software
12 month warranty
Option 1 - 100 Input and 100 Output Hopper
Option 2 - 100 Input Hopper and 1 card Output
SCAPS SAMLight: Built in Computer with SCAPS SAMLight, Windows 11 Pro
SDK & web-based software tools
Colour graphics display for status & monitoring
Active carbon filter
Card rejection function
Flip mechanism
Ethernet LAN output

Engraving Options

Microtext
Ghost Image
Sub surface printing
Tactile

Electrical

200W, 190-240 VAC 50HZ AC/DC external power supply, included as standard

Operating Conditions

Temperature: 18°C to 30°C
Humidity: 40% to 70%

Physical Specifications

Height 454mm
Width 200mm
Depth 360mm
Weight 18 kg

Options

Optional contact and contactless encoding & Magnetic encoder
Magnetic tracks ISO track 1,2,3
Professional services on request
Extended warranty
MLI (Multiple Laser Image) security engraving
Installation and training

Card Specification

Card thickness 30mil
Card size ISO 7810 format, CR80, ID-1
Card material: PC, laser-ready PVC
Technology cards contact and/or contactless with and without magnetic stripe

Additional Information

SwiftLaser® SLD100 is a Class 1 laser product
